EN
45
ADJUSTING THE MOWING HEIGHT
WARNING!
1. Pull the lever to adjust the mowing height
out and move it the position for the
required mowing height.
2. Release the lever to hook it in the required
position.
FIG. 7
USE
WARNING!
Always remove the cap from the spark plug,
switch o the lawn mower, and wait until
all moving parts have completely stopped
before carrying out any maintenance and/or
cleaning.
ENGINE OIL
NOTE:
• The engine is supplied without oil and
fuel. Always ll up with fuel and engine
oil before using for the rst time.
• Do not run the engine without enough
oil – risk of serious engine damage.
• Do not carry out any adjustments while
the lawn mower is running.
• Use good grade of 4-stroke engine oil.
• Do not screw in the dipstick when
checking the level – just insert it up to
the thread.
• Change the engine oil after the rst
5 hours of operation.
Filling engine oil
1. Place the lawn mower on a level surface
with the engine switched o.
2. Unscrew the oil ller plug and wipe the
dipstick.
FIG. 8
PARTS
A. Spark plug spanner
B. Wing nuts with screw M8
C. Coach bolt M8 x 45
D. Screws M8 x 35
E. Clamp
F. Bottom handle
G. Deck with top handle
H. Grass catcher
FIG. 2
HANDLE
1. Fit the bottom handle on the lawn mower
with 1 screw (D) and 1 wing nut (B) on
each side.
FIG. 3
2. Fold out the top handle and lock in place
by tightening the wing nuts (B) and screws
(C). Check that the guide for the starter
cord is on the right side of the handle,
seen from behind the lawn mower.
FIG. 4
3. Fasten the cord to the engine lever in the
clamp.
4. Pull the starter handle towards the top
handle.
5. Hold the starter handle and carefully pull
out the starter cord so that the handle
just goes past the guide. Hook the starter
handle in the guide.
FIG. 5
GRASS CATCHER
1. Lift up the ejector ap with one hand and
hook on the grass catcher.
2. Release the ejector ap to lock the grass
catcher in place.
FIG. 6
