50
TECHNICAL DATA
Voltage 12 VDC
Max drill diameter 10 mm
Speed 0–550 rpm
Sound power LWA 92.1 dB, K= 3 dB
Sound power level LpA 81.1 dB, K= 3 dB
Vibration (drilling) 2.10m/s², k=1.5m/s²
Vibration (screwing) 0.76m/s², k=1.5m/s²
Charging time: 3–5 hours
Battery capacity 1300 mAh
Always wear ear protection.
DESCRIPTION
1. Torque setting ring
2. Quick chuck
3. Power switch with speed control
4. Rotation selector
5. Handle
6. Lock button battery
7 Battery
8. Mains adapter
9. Status lamp on battery
1
3
5
6
7
4
2
8
9
