Mega FSF500-6W - WARNING

17
18
19
20
21
13
14
15
16
6
12
1
2
3
4
5
7
8
9
10
11
17
18
19
22
21
23
24
25
26
By-passes filter for circulating water to pool
Used after backwash to flush dirt from valve
Cleaning Filter by reversing the flow
By-passes filter, used for vacuuming to waste or lowering water level
CLOSED Shuts off all flow to filter or pool
RECIRCULATE
WASTE
RINSE
BACKWASH
FILTER
Valve Position
Normal Filtration and Vacuuming
Function
THIS FILTER OPERATES UNDER HIGH PRESSURE. WHEN ANY PART OF THE CIRCULATING
SYSTEM (e.g., CLAMP, PUMP, FILTER, VALVES, ETC.) IS SERVICED, AIR CAN ENTER THE
SYSTEM AND BECOME PRESSURIZED . PRESSURIZED AIR CAN CAUSE THE LID OR VALVE
TO BE BLOWN OFF WHICH CAN RESULT IN SEVERE INJURY, DEATH, OR PROPERTY
DAMAGE TURN PUMP OFF BEFORE CHANGING VALVE POSITION.
TO PREVENT DAMAGE TO THE PUMP AND FOR PROPER OPERATION OF THE SYSTEM.
CLEAN PUMP STRAINER AND SKIMMER BASKETS REGULARLY.
DO NOT UNSCREW SCREWS OF FLANGE CLAMP WHILE PUMP IS RUNNING.
WARNING
!
!
!
!
EM-MV40B VALVE REPLACEMENT PARTS
4-4
E
N
G
L
I
S
H
Item
Part No.
Description
1
01013003
Handle(Big)
2
03018008
Pin for Handle
3
01181001
Washer for Handle
4
89280107
M6×30 Screw with Nut for Standard Lid
5
01013004
1.5"Top Mount Valve Standard Lid (Black)
6
02011002
O-Ring for 1.5" Valve Lid
7
01181002
Washer for Spring
8
03014001
Spring for 1.5" Top Mount Valve
9
02011022
O-Ring for 1.5" Valve Rotor
10
01021001
1.5" Valve Rotor
11
02311002
Spider Gasket
12
01013007
1.5"Top Mount Valve Bottom Body Clamp (Black)
13
01013011
1.5" Diffuser
14
02011001
O-Ring for Diffuser
15
01013012
1.5"Top Mount Valve Over Drain Diffuser
16
02011134
O-Ring
17
02011151
O-Ring for 1.5"Connector
18
01013015
1.5"Connector (Black)
19
02011003
O-Ring for 1.5"Union
20
01171153
1.5"Union (A/E)
21
01013017
1.5"Union Nut (Black)
22
01041002
1.5"Union With Sight Glass (short)
23
01172026
1.5"Union With Sight Glass Holder
24
01111048
Connector for pressure gauge/stopper
25
89021703
Drain Plug with O-ring
26
06011029
Oil Pressure Gauge With O-ring (40Psi)
