Megger MFT-X1 Quick Start Guide

Auto Sequence Trip Time (RCD)
1
2
AC
AC(S)
A
A(S)
B
B+
F
10mA
30mA
50mA
100mA
300mA
500mA
650mA
1000mA
AUTO
1xI
2xI
5xI
Ramp
Touch
Voltage
3
MVC1010
Optional connection
4
<1 sec
5
RCD Trip Current (Ramp)
1
2
0 deg
180 deg
AC
AC-S
A
A-S
B
B+
F
10mA
30mA
50mA
100mA
300mA
500mA
650mA
1000mA
AUTO
½xI
1xI
2xI
5xI
Touch Voltage
3
MVC1010
Optional connection
4
<1 sec
5
RCD tests
RCD/GFCI Prüfung / Test DDR / Prueba RCD
www.megger.com
10

Megger MFT-X1 Specifications

General

Power Supply	Rechargeable Li-ion battery
Phase Sequence Indication	Yes
Resistance Range	0.01 Ω to 100 kΩ
Protection Rating	IP54
Continuity Testing	0.01 Ω to 2000 Ω
Loop Testing	0.01 Ω to 2000 Ω
RCD Testing	Type AC, A, F, B, and B+
Frequency Measurement	15 Hz to 400 Hz
Insulation Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Voltage Range	12 V to 440 V AC/DC
Frequency Range	15 Hz to 400 Hz
Battery Life	Approximately 8 hours
