Megger MFT-X1 Quick Start Guide

Voltage tests
Spannungsprüfungen / Essais de tension / Pruebas de voltaje
1 Phase (V Hz)
1
2
V
mV
TRMS
AC
DC
3
MVC1010
4
* appears when bluetooth is enabled
* erscheint, wenn Bluetooth aktiviert ist
* apparaît lorsque le Bluetooth est activé
* aparece cuando el bluetooth está habilitado
3 Phase Voltage / Sequence (V Hz)
1
2
V
mV
TRMS
AC
DC
3
MVC1010
4
www.megger.com
4

Megger MFT-X1 Specifications

General

Power Supply	Rechargeable Li-ion battery
Phase Sequence Indication	Yes
Resistance Range	0.01 Ω to 100 kΩ
Protection Rating	IP54
Continuity Testing	0.01 Ω to 2000 Ω
Loop Testing	0.01 Ω to 2000 Ω
RCD Testing	Type AC, A, F, B, and B+
Frequency Measurement	15 Hz to 400 Hz
Insulation Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Voltage Range	12 V to 440 V AC/DC
Frequency Range	15 Hz to 400 Hz
Battery Life	Approximately 8 hours
