Lid open/closure
1. Open lid by lifting up front panel tab (1).
2. Fold-away underneath instrument (2 & 3) and push into retaining slot
(4).
Connection Panel
RCDT300 Series test lead connections
7
Mains plug test lead
connector
Single or 3Phase
connection
Neutral or 2nd
phase connection
Warning:
Refer to User
Guide
Maximum 300 V
connection across
terminals
Maximum 300 V
Phase to earth
allowed
)
