Chapter III Dex CM3000 15
Full-Digital Control CO2/MAG/MIG Multi-FunctionWelding Machine
Table3-26Parameters of Arc Ending
Function Code Unit Adjusting Range Step Length Default Value
F2D
0～10 Seconds
0.1 0
Spot Welding Time（F2E）
1. Long press "Function" key more than 3 seconds to enter into internal menu, turn the left knob to F2E.
2. Turn the right knob to adjust parameters under F2E (shown in table 3-27).
3. Short press "Function" key to exit internal menu, F29Eparameter settings is completed.
Table3-27 Parameters of Spot welding time
Function Code Unit Adjusting Range Step Length Default Value
F2E
0～10 Seconds
0.1 0
Software VersionQuery (FB0)
To query software version number.
1. Enter into the internal function, and adjust left panel knob to FB0 (shown in figure 3-7).
Fig.3- 7FB0 Display Interface
2. Press the "Fn" ke y, adjust the right panel knob tocheck software version, as shown in figure 3-8.
Fig.3- 8 FB0 Display Interface
Error Record Query（FB1）
The error record is total 200 groups. "F00"means power-on self-testing.
1. Enter into internal function, and adjust the left panel knob to FB1 (shown in figure 3-9).
2. Press the "Fn" ke y, adjust panel right knob to query error record.
Fig.3- 9 Error Query Display Interface
Machine Model Query (FB2)
1. Enter into internal function, and adjust lest panel knob to FB2 (shown in figure3-10).
