meilan BLADE - Installing Speed and Cadence Sensor

(1). Begin by removing the screw with the Allen key from the F-mount.
(2). Place the rubber pad around the handlebar. 2 rubber bands (thick and thin) for
you to choose based on the handlebar diameter of your bike.
(3). Replace and tighten the screw.
(4). Place the Blade in the mounting grooves and turn clockwise until it locks in place.
To remove, turn counterclockwise or clockwise and lift.
Installing the speed and cadence sensor (C3)
1
2 3
Speed and Cadence Sensor (C3) Speed Magnet Cadence Magnet Nylon Ties *4 Rubber Band
NOTE: The battery insulator sheet needs to be removed for the first use in order to activate the sensor.
1 2 3
2
