- 20 -
P7 – Lock the [+] and [-] buttons (Set buttons)
“01” - [+] and [-] buttons Locked
“00” - [+] and [-] buttons unlocked (default)
P8 – Functionality of T1 terminals
“00” - T1 terminals are not in use (default)
“01” - External sensor
“02” - Soft start in heat sensor (FC), Deicing in cool (AC)
“03” - Door switch
4. Technician settings (cont’)
P9 – Functionality of In1,0 terminals
“00” - In1,0 terminals are not in use (default)
“01” - T2 (Change over sensor)
“02” - *T3 (Soft start in heat sensor)
“03” - Remote On/Off switch
“04” - Remote Economy switch
“05” - External Passive Infrared detector (PIR)
* Where T1 terminals are used for external sensor,
the In1,0 terminals can be used for T3 sensor.
P10 – Window contact (terminals In1,0) polarity
“00” - Normally open (default)
“01” - Normally close
