meitav-tec MTS/V50 - 3 Wiring Diagram; 4 DIP Switch Settings; Switch 1 - Temperature Readings from CTU or from Panel

-10 -
1
2
3
7
8
Room panel
MTS/V500
CTU
Main board
1
2
3
7
8
Switch 1 – Temperature readings from CTU or fom room panel
Switch OFF
Readings from
room panel
(default)
Switch ON
Readings from
CTU
654321
ON
654321
ON
SW2 - Configuration
654321
ON
*Default
3. Wiring diagram
4. DIP Switch settings
Switch 2 – Always OFF
Switch 3 – Always OFF
Switch 4 – Always OFF
Switch 5 – Always ON
Switch 6 – Always ON
