5 First steps
Setup and Installation
PLEASE NOTE
Comply with the specifications of the technical manual during set-up and installation.
This contains all building-side requirements.
Record of installation and set-up
The responsible stockist is to complete the record of installation and setup as proof of the correct setup,
installation and commissioning. A copy is to be sent to MELAG. This is a constituent part of any guarantee
claim.
Feed water supply
The steam sterilizer requires the use of distilled or demineralized water water, known as feed water.
DINEN13060 requires that feed water be used in accordance with the guideline values in appendixC.
The steam sterilizer requires c. 3 L feed water for the first filling of the steam generator.
The feed water supply is effected either via the internal feed water tank or via a separate water treatment
unit (e.g. MELAdem 40/MELAdem 47). The used feed water, so called waste water is either collected in
the internal storage tank on the waste water side (left) and emptied manually or disposed of automatically
via a building-side waste water connection.
NOTICE
When connecting an external feed water supply it is necessary to connect an external
waste water outflow as well.
There is a risk that hot waste water might run through the emergency overflow.
Using the internal water storage tank
The internal storage tank holds max. 5 litres. This volume of feed water is sufficient for up to 7 sterilization
runs.
1. To fill the storage tank with fresh feed water remove
the lid and fill the right-hand chamber of the storage
tank with fresh feed water up to the MAX mark.
2. Set the feed water supply in the display
toINTERNAL, see settings, Water supply [}page
52].
