ConnectX-2 Ethernet Card User Manual Rev 1.6
Mellanox Technologies
35
A.2 MNPH29C-X[ST]R Specifications
A.3 Board Mechanical Drawing and Dimensions
All of the cards covered in this User Manual have the same mechanical drawing and share the
same dimensions as depicted in Figure 13 or Figure 14.
Table 11 - Specifications for MNPH29C-X[ST]R
Physical Power and Environmental
Size:
Air Flow:
10Gb/s Connector:
2.71in x6.60in (68.90mm x
167.65mm)
200LFM
a
SFP+
a. Air flow is measured ~1” from the heat sink between the heat sink and the cooling air inlet.
Vo l t a g e :
Typ. Power:
Maximum Power:
Temperature:
12V, 3.3V
Passive Cables 6.43W
Active Cables 7.83W
Passive Cables 7.08W
Active Cables 8.48W
0°C to 55°C
Protocol Support Regulatory
Ethernet:
PCI Express
IEEE Std 802.3ae 10 Gigabit Ether-
net
IEEE Std 802.3ad Link Aggregation
and Failover
IEEE Std 802.3x Pause
IEEE Std 802.1Q VLAN tags, .1p
priorities
IEEE Std 802.1p Priorities
IEEE P802.1au D2.0 Congestion
Notification
IEEE P802.1az D0.2 Enhanced
Transmission Selection
IEEE P802.1bb D1.0 Priority-based
Flow ControlMulticast
2.0 SerDes @ 5.0 GT/s
EMC:
Safety:
EMI:
RoHS:
FCC 47 CFR part 15:2007, subpart B
class A;
ICES-003:2004 issue 4, class A;
VCCI V-3/2008.04 class A;
AS/NZ CISPR 22-2006, class A.
EN 55022:1998 + A1:2000 + A2:
2003 class A,
EN 55024:1998 + A1:2001 + A2:
2003
EN 61000-3-2: 2006,
EN 61000-3-3:
1995+A1:2001+A2:2005
standards harmonized under EMC
Directive 2004/108/EC Article 6(2);
UL, EU: IEC, TUV, and CB
EN 60950-1:2006
CLASS 1 LASER PRODUCT
IEC 60 825-1:1993 + A1:1997 +
A2:2001
EN 60825-1:1994+A1:1996+
A2:2001”
RoHS R6
