WAVEFORMS
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
H-3
CRT
DEFLECTION
46
44
45
43
POWER ON
5ms
10V
POWER ON
20µs
5V
POWER ON
20µs
50V
POWER ON
20µs
50V
47
POWER ON
20µs
50V
