DISASSEMBLY INSTRUCTIONS
B1-1
1. REMOVAL OF MECHANICAL PARTS
AND P.C. BOARDS
1-1: BACK CABINET (Refer to Fig. 1-1)
1.
2.
3.
4.
1-3: TV/DVD BLOCK (Refer to Fig. 1-3)
1.
2.
3.
Remove the 2 screws (1).
Disconnect the following connectors:
(CP301, CP302, CP401 and CP403).
Remove the TV/DVD Block in the direction of arrow.
Fig. 1-3
1-4: POWER PCB (Refer to Fig. 1-4)
1.
2.
3.
4.
5.
1-2: CRT PCB (Refer to Fig. 1-2)
CAUTION: BEFORE REMOVING THE ANODE CAP,
DISCHARGE ELECTRICITY BECAUSE IT
CONTAINS HIGH VOLTAGE.
BEFORE ATTEMPTING TO REMOVE OR
REPAIR ANY PCB, UNPLUG THE POWER
CORD FROM THE AC SOURCE.
1.
2.
3.
Remove the Anode Cap.
(Refer to REMOVAL OF ANODE CAP)
Disconnect the following connector:
(CP801).
Remove the CRT PCB in the direction of arrow.
Fig. 1-1
Fig. 1-2
Remove the 5 screws (1).
Remove the 2 screws (2).
Remove the screw (3).
Remove the Back Cabinet in the direction of arrow.
Front Cabinet
(1)
(2)
(1)
(2)
(1)
(3)
(1)
Back Cabinet
Front Cabinet
CRT PCB
Remove the screw (1).
Remove the Main PCB Holder.
Remove the 2 screws (2).
Disconnect the following connectors:
(CP3802 and CP3803).
Remove the Power PCB in the direction of arrow.
Fig. 1-4
(1)
Main PCB Holder
(1)
(2)
TV/DVD Block
Front Cabinet
(1)
(1)
Power PCB
DVD Block
(2)
