GENERAL SPECIFICATIONS
G-1 TV CRT CRT Size / Visual Size 9 inch / 228.6 mmV
System CRT Type Normal
Deflection 90 degree
Magnetic Field BV/BH +0.45G / 0.18G
Color System NTSC
Speaker 2 Speaker
Position Side
Size 3 inch
Impedance 8 ohm
Sound Output Max 1.2W + 1.2W
10%(Typical) 0.8W + 0.8W
G-2 DVD System Color System NTSC
Disc DVD, CD-DA, CD-R/RW
Disc Diameter 120 mm , 80 mm
Deck Disc Loading System Front Loading
Motor 3 Motors
Pick up 1-Lens 2-Beams System
Playback time(Max) DVD DVD 1-Layer 135min (4.7GB)
DVD 2-Layer 245min (8.5GB)
CD 74min
Video CD --
Search speed Fwd 2-15 times / 4 step (DVD)
2-20 times / 4 step (CD)
Actual 2-45 times (DVD)
4-40 times (CD)
Rev 2-15 times / 4 step (DVD)
2-20 times / 4 step (CD)
Actual 2-45 times (DVD)
4-40 times (CD)
Slow speed Fwd 1/8-1/2 times
Actual --
Rev 1/8-1/2 times
Actual --
G-3 Tuning Broadcasting System US System M
System Tuner and System 1Tuner
Receive CH Destination US(w/CATV)
Tuning System F-Synth
Input Impedance VHF/UHF 75 Ohm
CH Coverage 2~69, 4A, A-5~A-1, A~I, J~W, W+1~W+84
Intermediate Picture(FP) 45.75MHz
Frequency Sound(FS) 41.25MHz
FP-FS 4.50MHz
Preset CH No
Stereo/Dual TV Sound US-Stereo
Tuner Sound Muting Yes
G-4 Signal Video Signal Input Level 1 V p-p/75 ohm
Output Level 1 V p-p/75 ohm
S/N Ratio (Weighted) 65dB
Horizontal Resolution at DVD Mode 400 Lines (TV Monitor)
500 Lines (Video Out)
RGB Signal Output Level --
Audio Signal Input Level -8.0dBm/50k ohm
Output Level
-8 dBm/ 1k ohm
(TV Mode,
0dB=0.775Vrms)
-12dBm/ 1k ohm
(DVD Mode, -
20dBFs
0dBFs=2.0Vrms)
Digital Output Level 0.5 V p-p/75 ohm
S/N Ratio at DVD (Weighted) 90 dB
Harmonic Distortion 0.06% (1kHz)
Frequency Response : at DVD 4Hz - 22kHz
at Video CD --
at CD 4Hz - 20kHz
G-5 Power Power Source AC 120V, 60Hz
DC 12 V
Power Consumption at AC 55W at 120V 60Hz
at DC 55W at 12V
Stand by (at AC) 5 W at 120V 60Hz
Per Year -- kWh/Year
Protector Power Fuse Yes
G-6 Regulation Safety UL
Radiation FCC
X-Radiation DHHS
Laser DHHS
G-7 Temperature Operation
+
5
o
C
~ +4
0
o
C
Storage
-2
0
o
C
~ +
60
o
C
A3-1
