1. CD DOOR
14.
 (Next/Skip Forward) Button
2. CD Door OPEN (Close) Area
15.
■ (Stop) Button
POWER Button.3
16.


(Play/Pause) Button
4. FUNCTION Button 17.
5. REPEAT Button 18.
6. PROG (Program) Button 19.
DIMMER Button
7.
20.
8. LCD Display
21.
9.
n
22.
10.
TREBLE Control Knob
23.
11. 24.
12.
25.
BASS Control Knob
13.
 (Previous/Skip Backward) Button
26.
1. FM Wire Antenna
3.
SPEAKER OUT R (Right) Jack
2.
SPEAKER OUT L (Left) Jack
4. AC Power Cord
1
2 3 4
VOLUME - Button
VOLUME + Button
AL SET (Alarm Set) Button
MUTE Button
AL ON/OFF (Alarm On/Off) Button
(Set) ButtonTIME
P- Button
P+ Button
SLEEP/SNOOZE Button
POWER Indicator
Remote Receiver
AUX-IN Port
