Merach MR-E07 - Elliptical Machine Assembly Instructions; Step 1: Installing Foot Tubes

A. Use the Square Neck Bolt(#36), Flat Washer(#6) and Cap Nut(#23) to fix the Front Foot
Tube(#35A) and Rear Foot Tube(#35B) on the Main Frame(#33) by the Multi-function Cross
Wrench(#A) as shown below.
Step 1: Install the Foot Tubes
Assembly Instructions
06
