eSprinter permissible axle loads
High-voltage battery E9V
Permissible gross mass [lbs | Kg] 9,370 | 4000
Axle Front axle Rear axle
Permissible axle load [lbs | kg]
4100 | 1860
4409 | 2000 with code A50
5511 | 2500
A50 Front axle with increased load capacity
(special equipment)
4.2.3 Approved tire sizes
ⓘ You can find information about the tires and rims
assigned to the vehicle model and any limitations:
• From your contact partner, see chapter2.1
Advice for Upfitters about the eSprinter
(→page14).
⑴ NOTE
In order to meet the weight and speed ratings for the
specific vehicle in use, the appropriate tires must be
used. You can find out about all of the changes and
all of the latest tire values from the Mercedes-Benz
Vans Order Center, see chapter2.1 Advice for Upfit-
ters about the eSprinter (→page14).
Please also see: https://www.mbusatirecenter.com/
4.2.4 Turning circle diameter
Comply with the international and national regulations
for vehicle approval and registration.
These include:
• UN R 79
• European Union: 97/27/EC
• European Union: Regulation (EU) 1230/2012
• European Union: 96/53/EC
The size of your vehicle's turning circle can be found
in the data sheets and 2D drawings (offer drawings).
Both are available in the product information system
ADVANTAGES (see Chapter 2.2.7 in the Body-Equip-
ment-Guideline for Sprinter Vans) via www.upfitterpor-
tal.com.
ⓘ You can find information and additional specifica-
tions on the axles, steering, brake system, suspen-
sion, and wheel alignment in the chapters of the
same name in the Body-Equipment-Guideline for
Sprinter Vans.
Mercedes-Benz | Supplemental Guideline for eSprinter – Model Series 907, Edition 2023-8
32
