Cup holders in the dashboard
Cup holder in dashboard stowage compartment
(example: right-hand side of vehicle)
:
Cup holder
i
If your vehicle is equipped with a twin co-
driver's seat, you will find further cup hold-
ers (Y page 236) in the folding table.
Cup holders in the center console
Cup holders in the center console
X
To open: pull out ashtray compart-
ment : by the recess.
Clamping arm ; of the cup holder opens
out fully.
i
Vehicles with the non-smoking package
have an additional cup holder instead of the
ashtray.
X
Place the beverage container into the cup
holder and push clamping arm ; against
the container.
X
To close: push ashtray compartment :
into the center console until it engages.
Bottle holder
Bottle holders : in the front doors (example: co-
driver's door)
Ashtray
Ashtray in the center console
Ashtray in the center console
X
Pull ashtray compartment : out by
recess ;.
X
To open: fold cover = upwards.
X
To remove the insert: hold the ashtray by
the recesses on the left and right and pull
the insert out to empty it.
X
To replace the insert: press it down into
the holder as shown.
Make sure that the insert is inserted cor-
rectly. Otherwise you will not be able to
close ashtray compartment :.
Ashtray
237
Stowing and features
