Section 6
-
Storage
90-864195070 JUNE 2007
Page 129
c.
Water circulating pump hose
a
6143
a -
Drain plug
d.
Fuel cooler to thermostat housing hose
a
6144
a -
Drain plug
e.
Check valve
a
6131
a -
Drain plug (if equipped)
