OPERATION
34
• Four fuses are located at the upper rear of the engine containing a
5 and three 20 amp fuses. A circuit breaker protects the fuel pump
wire harness.
20
4112
a
b
c
d
e
a
f
5
20
5
5
5
15
15
a - Fuse
b - Fuse block A
c - Fuse block B
d - 50 amp main power circuit
breaker
e - 50 amp fuel pump circuit
breaker
f - PCM
Fuse Holder (b) Fuse Holder (c)
5 amp Hour Meter A‑RED/
GRN
5 amp Fuel Pump Relay A‑RED/BLK
B‑RED/
ORN
B‑RED/
PNK
15 amp CAN/Main
Remote
C‑RED 20 amp IAC Boost
Bypass
C‑RED/
GRN
D‑RED/
PPL
D‑RED/
BLU
15 amp Constant Power E‑RED 20 amp Coil Power E‑RED/
GRN
F‑RED/BLU F‑RED/YEL
5 amp Accessories G‑PPL 20 amp Fuel Injectors G‑RED/
GRN
H‑PPL/
WHT
H‑RED/
WHT
