Mercury Racing HP1075 SCi - Remote Controls (Console Mounted Zero Effort)

OPERATION
36
Analog gauges (if equipped) are protected with a 5 amp fuse.
a
b
c
d
f
e
7412
a - Helm harness connection
b - Fuse (5 amp)
c - Relay
d - Ground
e - Fused 12V (5 amp
maximum)
f - Switched 12V
Remote Controls (Console Mounted Zero Effort)
1. Control the throttle by moving the longer control lever(s) or, to
increase speed, push the control lever forward. Detents give the
movement of the lever a notched, precise feel. The detents also help
hold the lever at the desired engine RPM to reduce operator fatigue.
!
CAUTION
Avoid possible engine damage. Never shift the unit into or out of gear
unless the engine is at idle RPM.
