MAINTENANCE
56
CHECKING POWER TRIM PUMP FLUID
1. Place the drive unit in the full down/in position.
a
b
c
114
7432
a - Fill/Vent screw
b - "FULL" mark
c - "ADD" mark
Tube Ref No. Description Where Used Part No.
114
Power Trim and
Steering Fluid
Trim pump 92-802880A1
