3. Tighten the bottom screws to the specified torque.
a - Shipping bracket
b - Top screws
c - Bottom screws
Description Nm lb‑in. lb‑ft
Bottom screws 7.9 70
Steering Cable ‑ Starboard Side Routed Cable
1. Lubricate O‑ring seal and entire cable end.
3724
95
Tube Ref
No.
Description Where Used Part No.
95
2-4-C with PTFE O-ring seal and entire cable end 92-802859A 1
2. Insert steering cable into tilt tube.
c
b
c
a
47720
OUTBOARD INSTALLATION
eng 111
