Mercury 100 FourStroke - Fastening the Outboard to the Transom

3. Tighten the nut to the specified torque.
47708
Description Nm lb‑in. lb‑ft
Nut 47.5 35
Fastening the Outboard to the Transom
MOUNTING BOLTS
Outboard Transom Mounting Hardware ‑ Supplied with Outboard
Part Number Part Name Description
67755‑1 Outboard mounting bolt ½‑20 x 4.50 in. long (2.25 in. thread)
826711‑17 Nylon insert locknut ½‑20
28421 Flat washer 1.50 in. diameter
54012 Flat washer 0.875 in. diameter
Available Outboard Mounting Bolts
Part Number Description
67755005 ½‑20 x 2.50 in. long (1.25 in. thread)
67755006 ½‑20 x 3.50 in. long (1.25 in. thread)
814259 ½‑20 x 4.00 in. long (2.25 in. thread)
67755‑1 ½‑20 x 4.50 in. long (2.25 in. thread)
8M0033366 ½‑20 x 5.00 in. long (3.25 in. thread)
67755‑003 ½‑20 x 5.50 in. long (3.25 in. thread)
67755‑2 ½‑20 x 6.50 in. long (2.75 in. thread)
8M0028080 ½‑20 x 7.50 in. long (2.75 in. thread)
8M0032860 ½‑20 x 8.00 in. long (2.75 in. thread)
OUTBOARD INSTALLATION
112 eng
