GENERAL INFORMATION
18
Component Identification
a
b
c
d
e
f
g
h
i
3403
a - Top cowl
b - Bottom cowl
c - Water pump indicator hole
d - Driveshaft housing
e - Anti-ventilation plate
f - Auxiliary tilt switch
g - Transom brackets
h - Gearcase
i - Cooling water intake holes
