MAINTENANCE
108
2. Install the upper half of the flywheel cover sub-assembly to the
lower flywheel cover sub-assembly. Ensure the upper
flywheel cover latch opening is properly secured to the lower
flywheel cover.
a
b
14314
a - Upper flywheel cover
latch opening
b - Lower flywheel cover
latch
3. Push the two sub-assemblies together and install three
screws. Tighten the three screws to the specified torque.
14309
Description Nm lb. in. lb. ft.
Screw 6 53
4. Install the flywheel cover onto the resonator and the front
mounting post.
5. Align the flywheel cover rear bolt holes with the rear mounting
posts.
