Mercury 150 EFI User Manual

1
2
3
4
5
6
7
General Information
& Specifications
Ignition System
Fuel System
Powerhead
Mid-Section
Gear Housing
Attachment/Control Linkage
8
Color Diagrams
90-883728 JULY 2001 Page iii
Service Manual Outline
Section 1 - General Information & Specifications
A - Specifications
B - Maintenance
C - General Information
D - Outboard Installation
Section 2 - Electrical
A - Ignition
B - Charging & Starting System
C - Timing, Synchronizing & Adjusting
D - Wiring Diagrams
Section 3 - Fuel System
A - Fuel Pump
B - Fuel Injection
C - Oil Injection
D - Emissions
Section 4 - Powerhead
A - Powerhead
B - Cooling
Section 5 - Mid-Section
A - Clamp/Swivel Brackets & Drive Shaft Housing
B - Power Trim
Section 6 - Gear Housing
A - Right Hand Non-Ratcheting
B - Left Hand Non-Ratcheting
Section 7 - Attachments/Control Linkage
Section 8 - Color Diagrams

Mercury 150 EFI Specifications

General

Engine Type	4-stroke
Displacement	3.0L
Horsepower	150 HP
Fuel Induction System	Electronic Fuel Injection (EFI)
Alternator	60 amp / 756 watt
Gear Ratio	1.92:1
Cylinders	4
Starting	Electric
Warranty	3 years
Shaft Length	20", 25"
Weight	455 lbs
Full Throttle RPM Range	5000-5800 RPM
