OUTBOARD INSTALLATION
109
2. Place the neoprene wrap around the wiring, hoses, and
control cables, and place into the lower half of the front clamp.
a
b
29073
a - Neoprene wrap
b - Lower half of the front clamp
3. Join the top half of the front clamp with the bottom half. Secure
both halves together with cables ties.
a
b
29074
a - Top half of the front clamp
b - Cable ties
4. Secure the front clamp into the bottom cowl with the retainer
and two screws.

Mercury 200 Optimax Specifications

General

Gear Ratio	1.75:1
Full Throttle RPM Range	5000-5750 RPM
Horsepower	200 hp
Fuel Induction System	Direct Fuel Injection
Alternator Amp	60 amp
Shaft Length	20 in, 25 in
Starting System	Electric
Steering	Remote
