CHARGING & STARTING SYSTEM
90-883728 JULY 2001 Page 2B-23
(Centrifugal Bendix) Starter Motor
TORQUE
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 STARTER MOTOR
2 1 DRIVE KIT
3 1 DRIVE
4 1 DRIVE END PLATE
5 2 THRU BOLT 70 8
6 1 WASHER
7 1 ARMATURE
8 1 BRUSH SET
9 2 BRUSH HOLDER
10 2 SCREW
11 1 END CAP
12 2 COLLAR
13 2 RUBBER STOP
14 1 SCREW (1/4-20 x 5/8)
15 1 WIRE ASSEMBLY (BLACK)
16 1 LOCKWASHER
17 1 NUT
18 1 BATTERY CABLE (POSITIVE)
19 1 DECAL-Warning-High Voltage
