CHARGING & STARTING SYSTEM
90-883728 JULY 2001 Page 2B-39
Starter Motor (Solenoid Driven Bendix)
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 2 THRU BOLT 110 12.5
2 2 SCREWS 30 3.4
3 1 END CAP
4 1 BUSHING
5 1 BRUSH PLATE ASSEMBLY
6 1 ARMATURE
7 1 FIELD FRAME
8 1 SOLENOID
9 1 SHIELD
10 1 CUSHION
11 3 PLANETARY GEARS
12 1 PLUG
13 1 DISC
14 1 SHIFT FORK
15 1 GEAR/CLUTCH ASSEMBLY
16 1 BEARING
17 1 HOUSING
18 3 SCREW 40 4.5
19 1 DRIVE GEAR
20 1 SNAP RING
21 2 MOUNTING COLLAR
22 2 STOP
23 2 NUT 55 6.0
24 2 WASHER
25 1 NUT 20 2.3
