WIRING DIAGRAMS
90-883728 JULY 2001 Page 2D-31
Calibration 10.0 – The word “Trim” and the down and up arrows should be blinking. Trim the
unit out to the maximum trim (not trailer) position. Press the
button to save. Press
the
button to advance to the Calibration 25.0 setting.
Trim
Calibration 25.0 – The word “Trim” and up arrow should be blinking. Use the trim switch and
trim the unit out to the maximum trailer position. Press the
button to save. Press the
button to move to the next function.
Trim
ENGLISH OR METRIC READINGS SELECTION
The System Monitor allows you to display reading in the SAE (standard) English system or
the Metric system. Press the
button to toggle between units.
Gal
Ft
Psi
F
Ltr
M
Bar
C
SAE English System
Metric System
Press the button to save and move to the next function.
RANGE READINGS SELECTION
The System Monitor allows you to display reading in Miles, Nautical Miles or Kilometers.
Press the
button to toggle between units.
Range
Miles
Miles
Km
NMiles
Press the button to save and move to the next function.
DATA PAGE SELECTIONS
Select if you would like to display Depth, Trim, Engine Temperature, Oil Pressure, Oil Temper-
ature, Water Pressure, Volts, Engine Hours, and Data Simulator pages or not.
NOTE: The engine connected may not support all screen functions.
Press the button to toggle between units.
Press the
button to save and move to the next function.
To Next Page
