WIRING DIAGRAMS
90-883728 JULY 2001 Page 2D-51
SPEEDOMETER CALIBRATION CAL 1 LEVEL
REMOTE LCD LIGHT?
[NO]
[YES]
[SAVE]
Enables you to set the lighting levels on all the SC1000 simulta-
neously from this gauge.
REMOTE LCD CONTRAST?
[NO]
[YES]
[SAVE]
Enables you to control the contrast from another System TACH/
Speed simultaneously from this gauge.
TIME
[NO]
[EDIT]
[SKIP]
Allows you to set the time.
TIME FORMAT
[DOWN]
[UP]
[SAVE]
Choose between a 12 hour and 24 hour format.
USE GPS TIME?
[DOWN]
[UP]
[SAVE]
If you have a GPS connected this feature enables the gauge to
let the GPS update the gauges internal clock.
CALIBRATION HOUR 12:00 AM
[DOWN]
[UP]
[SAVE]
Adjust the gauges internal clock to match your local time. First
set the hours then press MODE button to set the minutes.
DISPLAY UNITS
[DOWN]
[UP]
[SAVE]
Lets you change units of measurement between English (stan-
dard) or Metric.
SPEED UNITS
[DOWN]
[UP]
[SAVE]
Lets you select the units at which speed is displayed. You can
choose from MPH (Miles Per Hour), KTS (Knots), or KMH (Kilo-
meters Per Hour).
TO WAY POINT SCREEN?
[NO]
[YES]
[SAVE]
If you have a GPS connected you can turn on the screen that
shows your distance and fuel to a way point.
SIMULATOR MODE?
[NO]
[YES]
[SAVE]
Do you want to turn on a simulation mode? (Used for demonstra-
tion purposes).
EXIT?
[NO]
[CAL2]
[YES]
Do you want to exit calibration? Or jump straight into calibration
level 2?
EXTERNAL SENSORS
[EDIT]
[SKIP]
This lets you enable or disable external sensor inputs.
