FUEL INJECTION
90-883728 JULY 2001 Page 3B-7
Fuel Management System
TORQUE
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
– 1 FUEL MANAGEMENT ASSEMBLY
1 1 ADAPTOR PLATE KIT
2 1 GASKET
3 1 GASKET
4 6 REED BLOCK
5 12 SCREW (1/4-20 x 0.88) 100 11.3
6 1 OIL PUMP
7 6 BUSHING
8 6 GROMMET
9 3 SCREW (M8 x 35) 140 16
10 6 WASHER
11 1 AIR PLENUM KIT
12 1 TEMPERATURE SENSOR 14 1.6
13 3 O-RING
14 2 SCREW (M4 x 16) Drive Tight
15 1 THROTTLE BODY KIT
16 1 O-RING
17 4 SCREW 100 11.5
18 3 SCREW 140 16
19 1 MAP SENSOR
20 1 BRACKET
21 1 SCREW (M6 x 16) 80 9
22 1 FUEL RAIL
23 6 FUEL INJECTOR
24 1 INJECTOR HARNESS
25 1 VAPOR SEPARATOR TANK
26 1 GROUND CABLE
27 1 SCREW (M6 x 10) Drive Tight
To Next Page
