POWERHEAD
90-883728 JULY 2001 Page 4A-9
Exhaust Manifold and Exhaust Plate
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 GASKET
2 1 DIVIDER PLATE
3 1 SEAL
4 17 SCREW (5/16-18 x 1-1/2) 16.5 22.5
5 2 SCREW (5/16-18 x 1) 16.5 22.5
6 1 COVER-RELIEF VALVE
7 4 SCREW (5/16-18 x 1-1/4) 16.5 22.5
8 1 SCREW (10-16 x 3/4 in.) 25 2.8
9 1 WASHER
10 1 DIAPHRAGM
11 1 WATER DEFLECTOR
12 1 PLATE
13 2 GASKET
14 1 SPRING
15 1 POPPET
16 1 GROMMET
17 1 CARRIER
18 1 GASKET
19 1 EXHAUST PATE
20 2 DOWEL PIN
21 1 SEAL
22 1 BRACKET
23 8 SCREW (10-16 x 1/2 IN.) 80 9
24 1 GROMMET
25 6 WASHER
26 6 NUT 23 31.0
27 1 BUSHING
28 1 SCREW (5/16-18 x 1-1/4 IN.) 25 34.0
29 1 SCREW (5/16-18 x 2-1/2 IN.) 25 34.0
30 3 SCREW (3/8-16 x 3-1/2 IN.) 50 68.0
31 1 FRONT BRACKET ASSEMBLY
32 4 SCREW (5/16-18 x 1/2 IN.) 25 34
33 4 WASHER
34 4 GROMMET
35 1 REAR BRACKET ASSEMBLY
36 1 GROMMET
37 1 SCREW (5/16-18 x 1-3/4)
