POWERHEAD
90-883728 JULY 2001 Page 4A-11
Crankshaft, Pistons and Connecting Rods
TORQUE
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm
1 1 CRANKSHAFT ASSEMBLY
2 1 WEAR SLEEVE
3 1 BALL BEARING (LOWER)
4 1 RETAINING RING
5 1 CARRIER ASSEMBLY
6 1 SEAL
7 7 RING–SEALING
8 2 ROLLER BEARING
9 2 RACE
3 PISTON (STARBOARD)
10
3 PISTON (PORT)
11 12 PISTON RING
12 12 LOCK RING
13 6 CONNECTING ROD ASSEMBLY
14 12 SCREW
1st Torque: 15 lb-in
2nd Torque: 20 lb-ft
Turn screw addition-
al 90 degrees after
2nd torque.
15 12 WASHER
16 12 ROLLER BEARING ASSEMBLY
17 174 NEEDLE BEARING–PISTON END
