POWERHEAD
90-883728 JULY 2001 Page 4A-13
Cylinder Head
TORQUE
.
NO.
DESCRIPTION lb-in lb-ft Nm.
1
2 CYLINDER HEAD (150)
2 CYLINDER HEAD (175/200)
2 2 SEAL
3 6 SEAL
4 24 SCREW (0.375-16 x 2.30) SEE NOTE #1
5 4 DOWEL PIN
6 2 GASKET
7 2 COVER
8 2 THERMOSTAT
9 4 SCREW (M8 x 25) 16.5 22.5
10 1 ELBOW
11 1 HOSE [12-3/4 IN.(32.3 CM)]
12 1 FITTING
13 10 STA-STRAP
14 1 HOSE [13-1/2 IN.(34.3 CM)]
15 1 HOSE [4-1/2 IN.(11.4 CM)]
16 1 T-FITTING
17 1 FITTING
18 2 KNOCK SENSOR (200)
19 2 ADAPTOR (200) 20 27
20 2 WASHER (200)
21 2 SCREW (M10 x 35) (200) 15 20.3
22 2 TEMPERATURE SENSOR
23 2 O-RING
24 1 TEMPERATURE SENSOR
25 2 SCREW (M8 x 14) 16.5 22.5
26 1 RETAINER
NOTE # 1: APPLY LIGHT OIL TO THREADS - TORQUE TO 30 LB. FT. (40.5 Nm),
THEN TIGHTEN ADDITIONAL 90 DEGREES.
