POWERHEAD
90-883728 JULY 2001 Page 4A-15
Bleed System Routing
TORQUE
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 FITTING
2 1 TUBING [22 IN (55.8 CM)]
3 2 TEE FITTING
4 2 TUBING [1-1/2 IN (3.8 CM)]
5 1 TUBING [4-3/4 IN (12 CM)]
6 1 TUBING [3-1/2 IN (8.9 CM)]
7 3 CHECK VALVE
8 1 CHECK VALVE
NOTE: High pressure fuel hose from fuel pump in vapor separator to fuel rail fitting on air
plenum.
