POWERHEAD
Page 4A-26 90-883728 JULY 2001
3. Disconnect and/or remove the following:
58878
a
b
c
d
e
f
g
a-Fuel Pump Harness
Connector
b-High Pressure Fuel
Hose
c-Fuel Regulator Hose
d-Vent Hose
e-Ground Lead (hidden)
between VST and Air
Plenum
f-Fuel Inlet Hose
g-Water Sensor Lead
4. Remove 3 bolts securing vapor separator to air plenum.
58801
a
a-Bolts
