POWERHEAD
90-883728 JULY 2001 Page 4A-33
4. Remove exhaust manifold and seal.
51852
a
b
c
a-Exhaust Manifold
b-Seal
c-Gasket
5. Remove reed block housing from cylinder block.
51845
a
a-Reed Block Housing
6. Inspect reeds as outlined in “Cleaning and Inspection”.
7. Remove bolts from end caps.
