POWERHEAD
90-883728 JULY 2001 Page 4A-75
6. Install 10 flat washers,and 10 locknuts which secure powerhead to exhaust extension
plate/driveshaft housing. Torque locknuts in 3 progressive steps until secured.
7. Disconnect hoist from Lifting Eye and remove Lifting Eye from flywheel.
8. Reinstall plastic cap into center of flywheel cover.
51846
a
a
a
a
a
a-Locknuts and Washers – Torque nuts to 20 lb. ft. (27 N m)
9. Connect water hose to fitting on exhaust adaptor plate.
58069
a
b
a-Water Hose
b-Fitting
