Mercury 200XRI User Manual

RIGHT HAND NON-RATCHETING
90-883728 JULY 2001 Page 6A-7
Gear Housing (Drive Shaft)(Standard Rotation)
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm
1 1 GEAR HOUSING (BLACK)(BASIC)
2 2 DOWEL PIN
3
1 STUD (3-1/8 IN.) (LONG)
3
1 STUD (3-11/16 IN.) (X-LONG)
4 2 STUD (2-1/16 IN.)
5 1 STUD (3-3/8 IN.)
6 2 STUD (3-1/8 IN.)
7 1 FILLER BLOCK
8 1 ROLLER BEARING
9 2 ANODE
10 1 SCREW (M6 x 40)
11 1 NUT 60 7
12
1 HOSE (10 IN. - LONG)
12
1 HOSE (12 IN. - X-LONG)
13 1 FITTING
14
1 PINION GEAR (1.87:1- 15 TEETH)
14
1 PINION GEAR (2:1 - 14 TEETH))
15 1 WASHER
16 1 NUT 75 101
17 AR SHIM (006 thru 048)
18 2 SCREW–drain 60 7
19 2 WASHER
20 1 SHIFT SHAFT
21 1 O-RING
22 1 BUSHING ASSEMBLY 50 68
23 1 OIL SEAL
24 1 WASHER–rubber
25
1 DRIVE SHAFT (LONG)
25
1 DRIVE SHAFT (X-LONG)
26 1 ROLLER BEARING
27 1 CUP
28 1 RETAINER 100 135
29 1 WATER PUMP BASE
30 1 RETAINER
31 1 GASKET
32 1 O-RING
33 1 OIL SEAL
34 1 OIL SEAL
35 1 GASKET–lower
36 1 GASKET–upper
37 1 FACE PLATE
38 1 WATER PUMP BODY ASSEMBLY
39 1 INSERT
40 1 SEAL–rubber
41 1 lMPELLER
42 1 KEY
43 1 SCREW (#14-8 x 2-1/4 IN.) 35 4
44 2 WASHER
45 2 NUT 50 5.5
46 1 WASHER
47 1 NUT 50 5.5
48 1 SLEEVE
