RIGHT HAND NON-RATCHETING
90-883728 JULY 2001 Page 6A-9
Gear Housing (Prop Shaft)(Standard Rotation)
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm
1 1 GEAR HOUSING(BASIC)
49 1 CAM FOLLOWER
50 1 SHIFT CAM
51 1 ROD
52
1 FORWARD GEAR (1.87:1 – 15/28)(150)
52
1 FORWARD GEAR (2:1 – 14/28)(115/135)
53 AR SHIM (.006 thru 050)
54 1 TAPERED ROLLER BEARING
55 1 CUP
56 1 NEEDLE BEARING
57 1 CLUTCH
58 1 CROSS PIN
59 1 DETENT PIN
60 1 SPRING
61 1 PROPELLER SHAFT
62
1
REVERSE GEAR (1.87:1 - 15/28)
62
1 REVERSE GEAR (2:1 – 14/28)
63 1 THRUST SPACER
64 1 THRUST RING
65 1 BALL BEARING
66 1 O-RING
67 1 BEARING CARRIER ASSEMBLY
68 1 ROLLER BEARING
69 1 OIL SEAL (INSIDE)
70 1 OIL SEAL (OUTSIDE)
71 1 KEY
72 1 TAB WASHER
73 1 COVER 210 285
74
1 TRIM TAB
74
1 ANODIC PLATE (TRACKER/150 LONG)
75 1 SCREW (1-3/4 IN.) 25 34
76 1 SCREW (3/8-16 x 1 IN.) 30 41
77 2 WASHER
78 2 NUT 50 68
