Mercury 200XRI User Manual

LEFT HAND NON-RATCHETING
90-883728 JULY 2001 Page 6B-9
Gear Housing (Prop Shaft)(Counter Rotation)
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 GEAR HOUSING (BLACK)(BASIC)
50 1 CAM FOLLOWER
51 1 SHIFT CAM
52 1 ROD
53 AR SHIM SET
54 1 BEARING ADAPTOR ASSEMBLY
55 1 ROLLER BEARING
56 1 THRUST WASHER
57 1 THRUST BEARING
58
1 REVERSE GEAR (1.87:1 – 15/28)
58
1 REVERSE GEAR (2:1 – 14/28)
59 1 ROLLER BEARING
60 1 SPRING
61 1 SLIDING CLUTCH
62 1 CROSS PIN
63 1 DETENT PIN
64 1 PROPELLER SHAFT
65
1 FORWARD GEAR (1.87:1 – 15/28)
65
1 FORWARD GEAR (2:1 – 14/28)
AR SPACER SHIM .206 IN.
AR SPACER SHIM .208 IN.
AR SPACER SHIM .210 IN.
AR SPACER SHIM .212 IN.
AR SPACER SHIM .214 IN.
AR SPACER SHIM .216 IN.
66
AR SPACER SHIM .218 IN.
AR SPACER SHIM .220 IN.
AR SPACER SHIM .222 IN.
AR SPACER SHIM .224 IN.
AR SPACER SHIM .226 IN.
AR SPACER SHIM .228 IN.
AR SPACER SHIM .230 IN.
