IGNITION
Page 2A-22 90-883728 JULY 2001
Symptom Cause Action
1. Engine cranks but will
not start (continued)
1.7 ECM not functioning
1.8 Crank Position Sensor not
functioning
Check for proper operation by
using Inductive Timing Light
91-99379.
Check battery voltage
(RED/YEL Lead) @ ignition
coils.
Check for blown fuse (C15).
Check battery voltage to fuse
from main power relay
(PURPLE Lead).
Check for shorted stop wire
(BLK/YEL).
Check crank position sensor
setting [0.025 in. – 0.040 in.
(0.64 mm – 1.02 mm)] from
flywheel or for defective crank
position sensor.
Defective ECM.
Power Supply:
Clean and inspect remote control
male and female harness connec-
tors.
– Sensor faulty.
– Bad connection
– Air gap incorrect
2. Engine cranks, starts
and stalls
2.0 Abnormally high friction in
engine
Check for scuffed piston or other
sources of high friction.
2.1 Air in fuel system/lines Crank and start engine several
times to purge.
2.2 TPS malfunction Check motion of throttle arm. Stop
nuts should contact block at idle
and WOT. Check TPS set-up. Must
connect DDT with adapter harness
(84-822560A5) to ECM.
2.3 Remote control to engine
harness connection is poor
Clean and inspect male and fe-
male connectors.
