OUTBOARD INSTALLATION
eng 113
2. Assemble the steering link rod to the engine with the special
washer head bolt "a" and self‑locking nylon insert locknut
"b."
3. Torque the head bolt, then the locknut to specifications.
Description Nm lb‑in. lb‑ft
Cable coupler nylon insert locknut
"d"
Tighten locknut until it seats, then
loosen ¼ turn.
Head bolt nylon insert locknut "b" 27 20
Special washer head bolt 27 20
