Mercury 250 Pro XS OptiMax User Manual

GENERAL INFORMATION
42 eng
Component Identification
1 - Top cowl
2 - Front cowl latch
3 - Auxiliary tilt
switch
4 - Clamp/swivel
bracket
5 - Gearcase
6 - Cooling water
intake
7 - Skeg
8 - Anti‑ventilation
plate
9 - Anodes (one per
side)
10 - Driveshaft
housing
11 - Bottom cowl
12 - Water pump
indicator
(tell‑tale)
13 - Side cowl latches
(both sides)
1
7493
2
3
4
5
6
7
8
9
10
11
12
13
