MAINTENANCE
eng 107
6. Coat the propeller shaft with Quicksilver or Mercury
Precision Lubricants Anti‑Corrosion Grease or 2‑4‑C with
PTFE.
Tube
Ref No.
Description Where Used Part No.
94
Anti-Corrosion
Grease
Propeller shaft 92-802867Q 1
95
2-4-C with
PTFE
Propeller shaft 92-802859A 1
7. Install front thrust hub, propeller, rear thrust hub washer and
propeller nut onto the shaft.
a - Propeller nut
b - Rear thrust washer
c - Propeller
d - Forward thrust hub
8. Place a block of wood between gearcase and propeller and
torque propeller nut to specification.
NOTE: If the propeller nut does not align with the propeller shaft
hole after tightening to the specified torque, then tighten the nut
further to align it with the hole.
