Mercury 30 EFI FourStroke User Manual

FEATURES AND CONTROLS
eng 61
• Tiller handle lock cap ‑ Remove the lock cap on top of tiller
handle to lock in up position. Push tiller lock release lever to
release the handle from the locked up position.
a - Lock cap
b - Locking mechanism
• Engine stop switch
28537
• Throttle grip friction knob ‑ Turn friction knob to set and
maintain the throttle at desired speed. Turn the knob
clockwise to tighten the friction or turn the knob
counterclockwise to loosen the friction.
a - Loosen friction
(counterclockwise)
b - Tighten friction (clockwise)
a
b
3273
a
b
28542
