MAINTENANCE
eng 77
Tube
Ref No.
Description Where Used Part No.
34
Special
Lubricant 101
Co-pilot, swivel bracket,
transom clamp screws, tiller
handle bushing, shift handle
detent
92-802865Q02
• Co‑pilot ‑ lubricate threads.
• Swivel bracket ‑ lubricate through fittings.
a - Swivel bracket lubrication
fittings
b - Co‑pilot
• Transom clamp screws ‑ lubricate threads.
a - Transom clamp screws
NOTE: Lubricating the tiller handle bushing and shift detent
shaft requires disassembly of the product. These points should
be lubricated at least once a year by an authorized dealer.
